Inicio /Productos/Máquina que barniza ULTRAVIOLETA/High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm

High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm

1 juego
MOQ
To Be Negotiated
Precio
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Nombre del producto: Máquina de recubrimiento de manchas UV y recubrimiento general de alta velocidad 9500 hojas/hora
Tamaño de Max.Sheet: Tamaño de Max.Sheet
Tamaño máximo de la capa: Para las máquinas de la categoría N2
Espesor de la hoja: 80-500gsm
Espesor de recubrimiento máximo: 0.025 mm
Medios de recubrimiento: Barniz con base de agua o UV
Resaltar:

Max Coating Size 720x1050mm UV Varnishing Machine

,

Sheet Thickness 80-500gsm UV Coating Machine

,

Max Coating Thickness 0.025mm Spot and Overall Coating Machine
Información básica
Lugar de origen: Porcelana
Nombre de la marca: EcooGraphix
Certificación: CE
Número de modelo: Ecoo SD-1060W
Pago y Envío Términos
Detalles de empaquetado: Paquete de exportación estándar
Tiempo de entrega: 45 dias
Condiciones de pago: LC, T/T
Capacidad de la fuente: 200 sets/año
Descripción de producto
High Speed 9500 Sheets/hour UV Spot and Overall Coating Machine
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 0
Model: Ecoo SD-1060W
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 1
Product Parameters

The High Speed UV Spot and Overall Coating machine SD1060W features:

  • Upper-sway gripper-pass-sheet method enabling maximum speed of 9500 sheets/hour
  • UV curing system with Teflon conveying belt for higher speed and precise orientation
  • UV curing higher efficiency with lower power consumption
  • Suitable for both thick and thin papers (80-500gsm)
  • Capable of both full and partial UV varnish coating or water based varnish coating
Application Sample
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 2
Specification
Model Ecoo SD-1060W
Max.sheet size 730x1060mm
MIN.sheet size 310X406mm
Max.coating size 720x1050mm
Sheet thickness 80-500gsm
Max Coating Thickness 0.025mm
Coating Media Water Base Varnish or UV Varnish
Coating registration accuracy ±0.2mm
Production speed 9000 sheets/hour
Weight 8 Ton
Dimension 10460x2725x1930mm
Power Max 44KW
Floor Plan
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 3
Coating Rollers
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 4
Coating with Anilox Roller
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 5
Coating with Rubber roller
FAQ
Q: What about the Installation and after-sales technician support?

A: Our engineer can assist with installation and provide necessary training. The buyer is responsible for round air plane tickets, service charge, and local accommodation costs. We provide 24/7 support for any questions or issues.

With numerous CTP installations worldwide, including direct purchases from EcooGraphix China, our technical service team supports these installations remotely with regular onsite visits. Our satisfied customers benefit from robust quality, seamless remote service, thorough training, and maintenance.

FACTORY
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 6 High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 7
etiqueta:

máquina de pintar ULTRAVIOLETA del punto de 260x190m m

máquina de pintar ULTRAVIOLETA del punto 60M/Min

Máquina de pintar ULTRAVIOLETA del punto que lamina
